StreamHighway TS Receiver

Product Description

StreamHighway TS Receiver


The SHP-R TS Receiver is a PCI V2.2 adapter card compliant to MPEG-II/DVB Standards. It provides the whole API functions and it's a perfect platform of hardware development of DTV devices. It's used to record transport stream data from various DTV devices on computer disks. It's can be used for DTV transport-stream recorders.

Features

·PCI rev2.2 compliant

·Universal PCI adapter for both 3.3V and 5V environments

·One ASI input and one loop-out output

·Supports ASI bit-rate range from 0 to 216Mbis/s

·On-board equalizer

·16M on-board high-speed buffer

·Support for MEPG-II/DVB/ATSC 188-byte and 204-byte packets ·Providing API functions Operating Systems

·Microsoft Windows 98/MENT4.02000XPServer2003Linux Development Platforms

·Microsoft Platform SDKMicrosoft Visual C++Borland DelphiBorland C++ BuilderGNU GCCï¼Linux¼‰ Applications

·Streamhighway TS B&R Platform

·DTV producing and testing device

·Data broadcasting server

·Video server ·DVB gateway

·Encoder and decoder

·Multiplexer

·DTV signal generator

·EPG server

·Non-linear editing device

·Stream analysis device

·Stream monitoring device

·DTV signal generator

·Program Inserting device

·Other DVB device Attributes PCI Compliance PCI 32 bit / 33 MHz / 5V PCI 32 bit / 33 MHz / 3.3V PCI 32 bit / 66 MHz / 3.3V On-board Buffer (MByte) 16 Maximum of Adapters 100 Input Bit Rate (Mbps) 216 Packet Size 188 / 204 Bit Rate Resolution (bps) 8 Input Level (mV) 200 ~ 880 Input Impendence  75 ASI Input Rate 270 Mbaud ± 100 ppm
